First of all, Many thanks to TitanNero for the super duper deal on this bumper, that came looking brand new, with factory speed yellow finish and all the grill, vents and even new stuff. One thing that amazed me was that the factory paint from this 2001 Turbo, matched perfectly my 2002 C2. Wow, I saved a buck or two on bodyshop charges!!!
On to the install...
Not difficult, nor easy... it's tricky. First, remember to have all the grills installed on the bumper prior to the installation.
You don't have to remove the wheels (I didn't) but it will help.
You don't have to remove the whole wheel liner but it will help.
You don't need to saw or cut part of the metal bumper. This is what you need to do: Paint in flat black the last 5" on each side. Now, on the side opening grills (the inside part) there is a plastic bracket that you must remove. If you don't, this will make installation impossible. Just a couple of plastic tabs and you're done. Then, place the bumper in place and screw the top 2 screws and 2 screws on each side (behind the side markers), then, move to the 1 screw on each side, at the bottom of the bumper. (the ones next to the fender) That's it. That's all that will align/match between the C2 bumper and the Turbo bumper.
My next step was to screw the bottom of the underside of the wheel liners (it was supposed to match the one in the bumper, but didn't...
Now, you are faced with 3 main anchor points at the bottom of your bumper that are 4" away from the bolting point.... You can create custom metal brackets with pre-perforated steel bands or even use tie-wraps!!! (I've seen it before!)
Now, if you are getting rid of your C2 bumper, (I was giving mine away but the guy wanted a techart instead... I don't blame him!) this is what you can do and it will look much better/cleaner than the other options.
Take your original C2 bumper and cut a segment of the bottom part of it. It's really easy and it even had a dotted line, like you are supposed to cut thru that!!!
I placed my newly created bracket and attached it to the mounting points in the frame and drilled small holes for the turbo mounting holes. Everything line up perfectly and it looks more cleaner.
Love it!
Well, enough rambling and enjoy the pics.
